THE EVOLVING TRANSFORMER · 07

DeepSeek V2 & V3

From Mixtral’s coarse 8-expert MoE to DeepSeek’s recipe: Multi-head Latent Attention (V2 introduces MLA; V3 scales it with decoupled RoPE), DeepSeekMoE (fine-grained routed experts + shared expert), and V3’s auxiliary-loss-free routing. One chapter, two production checkpoints — same family, different scale and training systems.

Mixtral
DeepSeek (you are here)
PaliGemma
236BV2 total · 21B active
671BV3 total · 37B active
MLAlatent KV cache
MoE160×6 → 256×8
DeepSeek V2 architecture
DeepSeek-V2 · 236B · MLA + DeepSeekMoE · top-6 · 2 shared
DeepSeek V3 architecture
DeepSeek-V3 · 671B · MLA + DeepSeekMoE · top-8 · 1 shared · no aux loss

This chapter covers DeepSeek-V2 (May 2024) and DeepSeek-V3 (Dec 2024) in one stop. Both are decoder-only sparse MoE models with MLA, RoPE, RMSNorm, and DeepSeekMoE feed-forward layers. V2 introduced the core architecture — latent KV compression plus fine-grained experts. V3 keeps that foundation but scales up, improves routing with auxiliary-loss-free load balancing, drops token dropping, adds Multi-Token Prediction, and trains with FP8 + DualPipe.

Sections 01–05 walk through runnable PyTorch for the V3 stack (deepseek_v3.py in Bumblebee). Section 06 is the architecture guide: V2 vs V3 side by side. Section 08 holds the comparison tables (Mixtral vs DeepSeek, plus the full V2/V3 summary).

Delta from Mixtral (05)

  • GQA + sliding window → MLA (cache compressed c_kv + small RoPE slice; decoupled nope/rope heads in V3)
  • 8 coarse experts, top-2, no shared path → DeepSeekMoE: 160 routed (V2) or 256 routed (V3), plus shared expert(s)
  • Mixtral MoE from layer 0 → V3 keeps first 3 layers dense SwiGLU
  • V3 only: auxiliary-loss-free expert balancing, no token dropping, 128K vocab, MTP + FP8 training

Full comparisons: §08 Comparison · V2 vs V3 architecture: §06.

00 · CONFIG

Production hyperparameters — V2 vs V3

Our teaching code scales these numbers down (see deepseek_v2.py and deepseek_v3.py). The diagrams above use the production values from the DeepSeek papers and HF configs.

V2 · hidden_size5120 · 60 layers · 100K vocab
V2 · MoE160 routed experts · top-6 · 2 shared experts
V2 · MLA16 attn heads · latent dim 512 · head dim 128
V3 · hidden_size7168 · 61 layers · 128K vocab
V3 · MoE256 routed experts · top-8 · 1 shared expert
V3 · MLA64 attn heads · latent dim 512 · head dim 128
Both128K context (YaRN extension) · RMSNorm · RoPE · SwiGLU experts
V3 · training14.8T tokens · MTP objective · FP8 mixed precision · DualPipe
01 · MULTI-HEAD LATENT ATTENTION (MLA)

V2 introduces MLA; V3 adds decoupled RoPE on a head slice

Delta vs Mixtral / LLaMA (GQA)

  • V2 (paper): compress K/V into shared latent c_kv — ~93% KV cache reduction vs full MHA. Production V2 uses MLA with RoPE (see diagram).
  • V3 (code below): splits each head into content (nope_head_dim) and position (rope_head_dim). Cache c_kv + small RoPE keys via w_kr; Q from w_down_q / w_qr.
  • K = cat(K_nope, K_rope); V = nope only. Same MLA idea at both scales; V3 is the recipe Kimi K2, GLM-4.5, and Mistral Large 3 copied.

MLA splits each head into a content (nope) part and a position (rope) part. KV path: w_down_kv compresses x → c_kv (cached); w_up_k/w_up_v expand to content K and V; w_kr bypasses the latent for RoPE keys (so positional encoding is exact). Q path: w_down_q → c_q; w_up_q + w_qr reconstruct Q. K = cat(K_nope, K_rope); Q = cat(Q_nope, Q_rope). V has nope_head_dim only.

deepseek_v3.pyMultiHeadLatentAttention

 1class MultiHeadLatentAttention(nn.Module):
 2    def __init__(self, config) -> None:
 3        super().__init__()
 4        self.dk           = config.dk            # nope_head_dim + rope_head_dim
 5        self.H            = config.H
 6        self.kv_lora_rank = config.kv_lora_rank
 7        self.q_lora_rank  = config.q_lora_rank
 8        self.dmodel       = config.dmodel
 9        self.nope_head_dim = config.nope_head_dim  # content part of head (no RoPE)
10        self.rope_head_dim = config.rope_head_dim  # position part of head (gets RoPE)
11        # ── KV path: compress x → c_kv (what gets cached), then expand to K, V ─────
12        self.w_down_kv = nn.Linear(self.dmodel, self.kv_lora_rank, bias=False)
13        self.w_up_k   = nn.Linear(self.kv_lora_rank, self.H * self.nope_head_dim, bias=False)  # content K
14        self.w_up_v   = nn.Linear(self.kv_lora_rank, self.H * self.nope_head_dim, bias=False)  # V (no RoPE)
15        self.w_kr     = nn.Linear(self.dmodel, self.H * self.rope_head_dim, bias=False)  # RoPE K bypasses latent
16        # ── Q path: compress x → c_q, then expand to Q_nope and Q_rope ─────────────
17        self.w_down_q = nn.Linear(self.dmodel, self.q_lora_rank, bias=False)
18        self.w_up_q   = nn.Linear(self.q_lora_rank, self.H * self.nope_head_dim, bias=False)  # content Q
19        self.w_qr     = nn.Linear(self.q_lora_rank, self.H * self.rope_head_dim, bias=False)  # RoPE Q from latent
20        # V has nope_head_dim per head only (no RoPE in values)
21        self.wo = nn.Linear(self.H * self.nope_head_dim, self.dmodel, bias=False)
22
23    def forward(self, x, rope, mask):
24        B, S, dmodel = x.shape
25        # ── KV path ───────────────────────────────────────────────────────────────
26        c_kv   = self.w_down_kv(x)  # (B, S, kv_lora_rank) — this gets cached
27        K_nope = self.w_up_k(c_kv).view(B,S,self.H,self.nope_head_dim).transpose(1,2)  # content K
28        K_rope = self.w_kr(x).view(B,S,self.H,self.rope_head_dim).transpose(1,2)  # position K (bypass latent)
29        K_rope = rope(K_rope)  # RoPE applied to position part only
30        K      = torch.cat([K_nope, K_rope], dim=-1)  # (B, H, S, dk)
31        # ── Value path ────────────────────────────────────────────────────────────
32        V = self.w_up_v(c_kv).view(B,S,self.H,self.nope_head_dim).transpose(1,2)  # V: nope only
33        # ── Q path ────────────────────────────────────────────────────────────────
34        c_q    = self.w_down_q(x)  # (B, S, q_lora_rank)
35        Q_nope = self.w_up_q(c_q).view(B,S,self.H,self.nope_head_dim).transpose(1,2)  # content Q
36        Q_rope = self.w_qr(c_q).view(B,S,self.H,self.rope_head_dim).transpose(1,2)  # position Q
37        Q_rope = rope(Q_rope)  # RoPE applied to position part only
38        Q      = torch.cat([Q_nope, Q_rope], dim=-1)  # (B, H, S, dk)
39        # ── Attention ─────────────────────────────────────────────────────────────
40        attn_score = Q @ K.transpose(-1, -2) / math.sqrt(self.dk)  # (B, H, S, S)
41        attn_score = attn_score.masked_fill(mask[:S, :S] == 0, float("-inf"))
42        attn_score = F.softmax(attn_score, dim=-1)  # (B, H, S, S)
43        x = attn_score @ V  # (B, H, S, nope_head_dim)
44        x = x.transpose(1,2).contiguous().view(B,S,self.H*self.nope_head_dim)  # (B,S,H*nope)
45        return self.wo(x)  # (B, S, dmodel)
cache: ckv = Wdown · h   |   Ki = Wup Ki · ckv   |   Vi = Wup Vi · ckv
▼ Show original version
model.pyGQABlock forward path (excerpt)

  1        # Mixtral / LLaMA: separate wk, wv; repeat_kv for GQA; RoPE on Q, K
  2        query = self.wq(x).view(...).transpose(1, 2)
  3        key = self.wk(x).view(...).transpose(1, 2)   # full or grouped KV heads
  4        value = self.wv(x).view(...).transpose(1, 2)
  5        # residual passes (Q, K, V, mask) into self_attention_block
02 · DEEPSEEKMOE (FINE-GRAINED MOE)

V2: 160 experts top-6 + 2 shared · V3: 256 experts top-8 + 1 shared

Delta vs Mixtral

  • Mixtral: 8 large experts, top-2, no shared path. DeepSeekMoE uses many small SwiGLU experts for finer specialization.
  • V2: 160 routed · top-6 · 2 shared experts · auxiliary load-balance losses · token dropping during training.
  • V3: 256 routed · top-8 · 1 shared expert · auxiliary-loss-free bias routing · no token dropping.

DeepSeek absorbs the shared expert directly into MoE(config). shared_expert runs unconditionally for every token; the routed dispatch loop (same pattern as Mixtral) handles the sparse path. Final output: shared_expert_out + output.

deepseek_v3.pyMoE (includes shared expert)

 1class MoE(nn.Module):
 2    def __init__(self, config) -> None:
 3        super().__init__()
 4        self.experts = nn.ModuleList(
 5            [SwiGLUFeedForward(config) for _ in range(config.num_experts)]
 6        )
 7        self.shared_expert = SwiGLUFeedForward(config)  # always-on expert
 8        self.router = MoERouter(config)
 9        self.top_k  = config.top_k
10
11    def forward(self, x):
12        shared_expert_out = self.shared_expert(x)  # runs for ALL tokens unconditionally
13        weights, indices = self.router(x)  # (B, S, top_k)
14        output = torch.zeros_like(x)  # (B, S, dmodel)
15        for k in range(self.top_k):
16            for i, expert in enumerate(self.experts):
17                mask = indices[:, :, k] == i  # (B, S) — tokens routed to expert i at slot k
18                if mask.any():
19                    expert_out = expert(x[mask])  # (num_selected, dmodel)
20                    selected_weights = weights[:, :, k][mask].unsqueeze(-1)  # (num_selected, 1)
21                    output[mask] += selected_weights * expert_out
22        return shared_expert_out + output  # shared + routed
deepseek_v3.pyMixtralConfig vs DeepseekConfig (MoE params)

  1    num_experts: int = 8   # Mixtral: 8 large experts
  2    num_experts: int = 4   # DeepSeek (scaled from 256): fine-grained experts
  3    top_k:        int = 2   # top-2 routed; plus 1 shared_expert always active
▼ Show original version
model.pyCoarse MoE (Mixtral-style, conceptual)

  1class MixtralMoEBlock(nn.Module):
  2    def __init__(self, d_model, d_ff, n_experts=8, top_k=2, ...):
  3        self.experts = nn.ModuleList([SwiGLUFeedForward(d_model, d_ff) for _ in range(8)])
  4        # 8 *large* experts, top-2 (not 256 fine-grained, top-8)
  5    def forward(self, x):
  6        ...  # route with MoERouter, combine top-k *weights* and expert outputs
03 · SHARED EXPERT

Shared expert: absorbed into MoE(config) — not a separate wrapper

Delta vs Mixtral

  • New: a self.shared_expert (always-on SwiGLUFeedForward) is embedded directly inside MoE(config), alongside the routed expert list. No separate wrapper class is needed.

In deepseek_v3.py, the shared expert is built directly into MoE(config) — there is no separate MoEWithSharedExpert wrapper. self.shared_expert is a SwiGLUFeedForward(config) that runs unconditionally in every forward pass. The return is shared_expert_out + output.

deepseek_v3.pyMoE.forward — shared + routed path

 1    def forward(self, x):  # inside MoE(config)
 2        shared_expert_out = self.shared_expert(x)  # runs for ALL tokens — unconditional
 3        weights, indices = self.router(x)  # (B, S, top_k)
 4        output = torch.zeros_like(x)  # accumulates routed expert contributions
 5        for k in range(self.top_k):
 6            for i, expert in enumerate(self.experts):
 7                mask = indices[:, :, k] == i  # (B, S) — tokens routed to expert i at slot k
 8                if mask.any():
 9                    expert_out = expert(x[mask])  # (num_selected, dmodel)
10                    selected_weights = weights[:, :, k][mask].unsqueeze(-1)  # (num_selected, 1)
11                    output[mask] += selected_weights * expert_out
12        return shared_expert_out + output  # shared + routed
▼ Show original version
model.pyRouted MoE only

  1    def forward(self, x):
  2        return self.routed_moe(x)  # no always-on SwiGLU path in Mixtral
04 · DECODER BLOCK (MLA + MOE)

Block(config, layer_idx) — MLA + conditional dense/MoE

Delta vs Mixtral

  • Attention sublayer is MultiHeadLatentAttention(config) — forward takes (x, rope, mask).
  • FFN is MoE(config) for layer_idx >= config.n_dense_layers, else dense SwiGLUFeedForward(config). The decision is made at construction time — no runtime branching.

Identical pre-norm two-residual pattern to Mixtral’s Block, but attention is mhla (MultiHeadLatentAttention) and FFN is conditionally MoE or dense SwiGLUFeedForward depending on layer_idx. rope and mask are shared from Deepseek.

deepseek_v3.pyBlock

 1class Block(nn.Module):
 2    def __init__(self, config, layer_idx) -> None:
 3        super().__init__()
 4        self.mhla  = MultiHeadLatentAttention(config)
 5        # first n_dense_layers use dense SwiGLU; later layers use MoE+shared
 6        if layer_idx >= config.n_dense_layers:
 7            self.ff = MoE(config)
 8        else:
 9            self.ff = SwiGLUFeedForward(config)  # dense for first n_dense_layers
10        self.rms_1 = RMSNorm(config)  # pre-norm for MLA
11        self.rms_2 = RMSNorm(config)  # pre-norm for FFN/MoE
12
13    def forward(self, x, rope, mask):
14        norm_x = self.rms_1(x)
15        x = x + self.mhla(norm_x, rope, mask)
16        x = x + self.ff(self.rms_2(x))
17        return x
▼ Show original version
model.pyDecoderBlock attention lambda

  1        x = self.residual_connections[0](x, lambda x: self.self_attention_block(x, x, x, mask))
  2        x = self.residual_connections[0](x, lambda x: self.self_attention_block(x, mask))  # MLA
05 · ASSEMBLE DEEPSEEK (V3)

Token embed, RoPE, N blocks, final norm, lm_head

Delta vs Mixtral

  • Layers 0 … n_dense_layers-1 use dense SwiGLUFeedForward (no MoE). Remaining blocks use MoE(config) (with shared expert built in). The decision is made per-block at construction time via layer_idx.
  • The DeepseekConfig dataclass centralizes all hyperparameters including MLA dims (kv_lora_rank, q_lora_rank, rope_head_dim, nope_head_dim) alongside MoE params (num_experts, top_k, n_dense_layers).

Deepseek(config) follows the same self-contained pattern as Mixtral and Mistral. Key differences: rope is initialized with config.rope_head_dim (not full dk); blocks are Block(config, layer_idx) so each block knows its own dense/MoE setting; mask is a full tril (no sliding window).

deepseek_v3.pyDeepseek

 1class Deepseek(nn.Module):
 2    def __init__(self, config) -> None:
 3        super().__init__()
 4        self.wte    = nn.Embedding(config.vocabsize, config.dmodel)
 5        # MLA uses rope_head_dim only — RoPE head dim is smaller than full dk
 6        self.rope   = RotaryPositionalEmbedding(config, config.rope_head_dim)
 7        self.blocks = nn.ModuleList(
 8            [Block(config, layer_idx) for layer_idx in range(config.N)]
 9        )
10        self.norm   = RMSNorm(config)
11        self.lm_head = nn.Linear(config.dmodel, config.vocabsize, bias=False)
12        self.lm_head.weight = self.wte.weight  # weight tying
13        # full causal mask (no sliding window — DeepSeek uses standard tril)
14        self.register_buffer("mask",
15            torch.tril(torch.ones(config.max_seq_len, config.max_seq_len)),
16        )
17
18    def forward(self, x):
19        x = self.wte(x)
20        for block in self.blocks:
21            x = block(x, self.rope, self.mask)
22        x = self.norm(x)
23        return self.lm_head(x)  # raw logits
▼ Show original version
model.pybuild_llama (excerpt — dense SwiGLU every layer)

  1def build_llama(vocab_size, max_seq_len, d_model=4096, N=32, h=32, n_kv_heads=8,
  2                dropout=0.0, d_ff=11008):
  3    for _ in range(N):
  4        self_attention_block = GQABlock(d_model, h, n_kv_heads, max_seq_len, dropout)
  5        feed_forward_block = SwiGLUFeedForward(d_model, d_ff, dropout)  # no MoE
  6        ...
06 · DEEPSEEK-V2 VS DEEPSEEK-V3

Same family, different scale and routing

Both are decoder-only Transformer MoE models: MLA, DeepSeekMoE, RoPE, RMSNorm, sparse expert activation, and 128K context after extension. V2 introduced the core architecture; V3 scales it and improves MoE routing, training efficiency, and the prediction objective.

Attention — mostly the same

V2 introduces Multi-head Latent Attention: instead of caching full K and V per head, MLA stores a compressed latent vector (plus a small RoPE-related slice at inference). The V2 paper reports ~93% KV cache reduction vs DeepSeek 67B and up to 5.76× generation throughput. V3 keeps MLA at larger scale — same attention idea, bigger tensors.

Attention typeKV cache
MHA (Transformer)Large — full K + V per layer, head, token
GQA (LLaMA / Mixtral)Smaller — grouped KV heads
MQAVery small, but often weaker quality
MLA (DeepSeek V2/V3)Very small while preserving strong quality

MoE / feed-forward — biggest architectural shift V2 → V3

Both use DeepSeekMoE: fine-grained routed experts, shared experts, sparse activation. V2 uses auxiliary losses for load balancing and token dropping during training. V3 replaces those with auxiliary-loss-free routing: a learnable bias on each expert’s score is nudged down when overloaded and up when underloaded — no extra loss terms forcing balance.

Load balancing & token dropping

V2: expert-level, device-level, and communication balance auxiliary losses; tokens can be dropped when loads skew. V3: bias-based balancing only; no token dropping in training or inference.

Scale, tokenizer, training

V2: 236B total, 21B active, 8.1T pretrain tokens, 100K vocab, next-token prediction. V3: 671B total, 37B active, 14.8T tokens, 128K vocab, adds Multi-Token Prediction (MTP) during training (also usable for speculative decoding), and makes FP8 mixed-precision + DualPipe pipeline parallelism central to economical training (~2.788M H800 GPU-hours reported).

One sentence: DeepSeek-V2 introduced MLA plus DeepSeekMoE; DeepSeek-V3 keeps that foundation, scales much larger, improves expert routing without auxiliary losses, removes token dropping, adds MTP, expands the tokenizer, and trains efficiently with FP8 and DualPipe.

08 · COMPARISON

Mixtral (05) vs DeepSeek V3 · DeepSeek V2 vs V3

Canonical tables for this chapter — same pairs as the delta card above.

Mixtral 8×7B vs DeepSeek V3

AspectMixtral (coarse MoE + GQA)DeepSeek V3
AttentionGQA: cache full K/V at head d_kMLA: cache low-rank c_kv + RoPE slice
FFN8 large experts, top-2; no always-on path256 small experts, top-8 + 1 shared expert
Early layersMoE from block 0 in our sketchFirst 3 blocks dense SwiGLU only
Load balancingRouter softmax + top-k (no DeepSeek aux system)Auxiliary-loss-free bias routing
Context32K (8×7B)128K (YaRN extension)

DeepSeek V2 vs DeepSeek V3 — quick summary

FeatureDeepSeek-V2DeepSeek-V3
Base architectureDecoder Transformer MoEDecoder Transformer MoE
AttentionMLA (introduced here)MLA (scaled)
FFNDeepSeekMoEImproved DeepSeekMoE
Load balancingAuxiliary lossesAuxiliary-loss-free routing
Token droppingYes (training)No
Total params236B671B
Active params / token21B37B
Layers6061
Hidden size51207168
Routed experts160256
Shared experts21
Active routed / token68
Vocabulary100K128K
Context128K128K
Pretraining tokens8.1T14.8T
Extra objectiveNo MTPMulti-Token Prediction
FP8 trainingNot centralYes (major contribution)
Main design goalEfficient open MoE modelLarger, stronger, more systems-efficient MoE
09 · REFERENCES

Papers & technical sources

Primary reports and references for this chapter. Read these for full equations, training details, and official hyperparameters.

Share this post

Comments
